HyperionProtocol

Chunked TCP messaging for .NET. Pluggable serialization, adaptive framing, streaming receive, and System.IO.Pipelines support — without the weight of a full RPC framework.

Overview

HyperionProtocol solves three problems that every long-lived TCP service in .NET eventually re-implements: message framing, chunking of payloads that don't fit in one socket write, and a clean boundary between the wire format and your serializer of choice. It does this with a small, focused public surface, four target frameworks, and no opinion about what your messages contain.

The package powers the Hyperion Omni Client but is independent: any .NET app that talks over NetworkStream — or anything that exposes a Stream / PipeReader / PipeWriter — can adopt it as a one-line replacement for hand-rolled framing.

When to reach for it

You want this library when you need a point-to-point binary protocol over TCP and you'd rather not write the framing yourself. Concretely, that means:

• A client and a server you own on both ends.
• Messages that may be small (a few bytes) or large (multi-gigabyte file transfers).
• A serializer you've already chosen — System.Text.Json, MessagePack, protobuf-net, MemoryPack, whatever — that you want to keep using as-is.
• An async/await codebase that benefits from IAsyncEnumerable and System.IO.Pipelines.

You probably don't want this library when you need browser interop (use WebSocket or SignalR), when you need full method-call RPC semantics with code generation (use gRPC), or when you need a message broker for pub/sub (use NATS or MQTT).

How it compares

Library / Approach	What it gives you	Schema / codegen	Native chunking	Streaming receive	Browser	Dep footprint
HyperionProtocol	Framing + adaptive chunking + pluggable serializer	None	Yes (default 1 MiB)	IAsyncEnumerable<ReadOnlyMemory<byte>>	No	System.IO.Pipelines
gRPC (Grpc.Net.Client)	Full RPC framework with services, methods, streaming	.proto + codegen	Via HTTP/2 framing	Yes (server-streaming RPCs)	Through grpc-web	Large (Grpc.*, HTTP/2 stack)
SignalR client	Real-time hub/RPC over WebSocket / SSE / long-poll	None at wire level, attribute-based at API	No (transport-level only)	Streaming hub methods	First-class	Large (Microsoft.AspNetCore.SignalR.Client + transports)
System.Net.WebSockets	Frame-based bidirectional messaging	None	No (you split & reassemble)	Manual	First-class	In-box
StreamJsonRpc	JSON-RPC 2.0 over any Stream	None	No	No (response is one message)	Through duplex pipe wrappers	StreamJsonRpc
Raw TcpClient + custom framing	Everything is yours	None	Whatever you write	Whatever you write	No	None

The honest pitch: HyperionProtocol sits in the gap between "raw TCP with handmade length-prefixed framing" and "a full RPC framework". If you're about to write your fifth [length:4][payload] loop and then realise you also need to chunk multi-megabyte payloads and stream them straight to disk, this is the package that already did all of that.

Install

dotnet add package TechTeaStudio.Protocols.Hyperion

Or pin a specific version in .csproj:

<PackageReference Include="TechTeaStudio.Protocols.Hyperion" Version="0.3.0" />

Quick start

Server

using System.Net;
using System.Net.Sockets;
using TechTeaStudio.Protocols.Hyperion;
using TechTeaStudio.Protocols.Hyperion.Protocols;

var listener = new TcpListener(IPAddress.Any, 8080);
listener.Start();

while (true)
{
    var client = await listener.AcceptTcpClientAsync();
    _ = HandleClientAsync(client);
}

async Task HandleClientAsync(TcpClient client)
{
    using (client)
    using (var stream = client.GetStream())
    {
        var protocol = new SmartHyperionProtocol(new DefaultSerializer());

        var message = await protocol.ReceiveAsync<string>(stream);
        await protocol.SendAsync($"Echo: {message}", stream);
    }
}

Client

using var client = new TcpClient();
await client.ConnectAsync("localhost", 8080);
using var stream = client.GetStream();

var protocol = new SmartHyperionProtocol(new DefaultSerializer());

await protocol.SendAsync("Hello HyperionProtocol!", stream);
var response = await protocol.ReceiveAsync<string>(stream);

Custom serializer

Implement ISerializer to plug in MessagePack, protobuf, MemoryPack, or anything else:

public sealed class MessagePackSerializer : ISerializer
{
    public byte[] Serialize<T>(T obj)   => MessagePack.MessagePackSerializer.Serialize(obj);
    public T Deserialize<T>(byte[] data) => MessagePack.MessagePackSerializer.Deserialize<T>(data);
}

var protocol = new SmartHyperionProtocol(new MessagePackSerializer());

The default DefaultSerializer already short-circuits string and byte[] to avoid round-tripping them through JSON.

Working with large payloads

Anything bigger than 64 KiB falls onto the chunked path (default chunk size: 1 MiB). For receivers that don't want to buffer the full message in memory, use the streaming variant — it yields each chunk as it arrives.

await using var file = File.Create("incoming.bin");
await foreach (var chunk in protocol.ReceiveStreamingAsync(stream))
{
    await file.WriteAsync(chunk);
}

Validation (magic, version, chunk order, end-flag, packet-id continuity) runs before every yield, so corrupt or out-of-order traffic surfaces as a HyperionProtocolException immediately, not after the whole payload has been read.

System.IO.Pipelines

For high-throughput services, use the Pipelines overloads for zero-copy writes and natural backpressure:

var writer = PipeWriter.Create(networkStream);
var reader = PipeReader.Create(networkStream);

await protocol.SendAsync(message, writer);
var response = await protocol.ReceiveAsync<MyType>(reader);

Adaptive framing

SmartHyperionProtocol picks the cheapest layout per message. You don't tune anything — the sender decides based on payload size:

Payload	Wire format	Overhead
< 1 KiB	[magic:1 = 0xFF][length:2 BE][data]	3 bytes
< 64 KiB	[magic:1 = 0xFE][length:4 BE][data]	5 bytes
anything else	chunked frames with a JSON PacketHeader (same as base HyperionProtocol)	~120 bytes per chunk

The receiver reads one byte to disambiguate: 0xFF/0xFE pick lightweight/direct, anything else is taken as the high byte of the chunked header-length prefix (a JSON header is always small enough that this byte is 0x00).

You can observe what the picker chose:

var stats = protocol.GetStatsSnapshot();
Console.WriteLine(stats);
// Protocol Stats:
// Lightweight: 42 (84.0%)
// Direct:       6 (12.0%)
// Chunked:      2  (4.0%)
// Bytes saved: 6,612

Protocol version negotiation

PacketHeader.Version is part of every chunked frame; the validator accepts versions in [MinSupportedProtocolVersion .. ProtocolVersion] (currently 0..1, with 0 treated as legacy v1 from 0.2.x senders). An optional handshake helper exchanges a magic preamble plus version on connection and returns the minimum both sides agree to speak:

int version = await HyperionProtocol.HandshakeAsync(stream);
if (version < HyperionProtocol.ProtocolVersion)
{
    // adapt: fall back to features the older peer understands
}

Wire format

Chunked frame (HyperionProtocol & SmartHyperionProtocol fallback):

  ┌──────────────────┬────────────────────┬─────────────────┐
  │ Header Length    │ JSON Header        │ Chunk Payload   │
  │ 4 bytes BE       │ N bytes (≤ 64 KiB) │ ≤ 1 MiB         │
  └──────────────────┴────────────────────┴─────────────────┘

Header (JSON):
  { "Version":1, "Magic":"TTS", "PacketId":"<guid>",
    "ChunkNumber":0, "TotalChunks":5, "DataLength":1048576, "Flags":0 }

Smart-mode framing for small messages skips the JSON header entirely:

  Lightweight (<1 KiB):  [0xFF][len:2 BE][data]
  Direct      (<64 KiB): [0xFE][len:4 BE][data]

Both ends of a connection must agree on ChunkSize and MaxHeaderLength; the receiver rejects oversized chunks and headers. The defaults are 1 MiB and 64 KiB respectively, configurable via HyperionProtocolOptions.

Public API

public class HyperionProtocol
{
    public const int ProtocolVersion = 1;
    public const int MinSupportedProtocolVersion = 0;

    public HyperionProtocol(ISerializer serializer);
    public HyperionProtocol(ISerializer serializer, HyperionProtocolOptions options);

    public int ChunkSize { get; }
    public int MaxHeaderLength { get; }

    // NetworkStream API
    public virtual Task SendAsync<T>(T message, NetworkStream stream, CancellationToken ct = default);
    public virtual Task<T> ReceiveAsync<T>(NetworkStream stream, CancellationToken ct = default);
    public virtual IAsyncEnumerable<ReadOnlyMemory<byte>> ReceiveStreamingAsync(NetworkStream stream, CancellationToken ct = default);

    // Pipelines API
    public virtual Task SendAsync<T>(T message, PipeWriter writer, CancellationToken ct = default);
    public virtual Task<T> ReceiveAsync<T>(PipeReader reader, CancellationToken ct = default);

    // Optional handshake
    public static Task<int> HandshakeAsync(NetworkStream stream, int? localVersion = null, CancellationToken ct = default);
}

public class SmartHyperionProtocol : HyperionProtocol
{
    public ProtocolStats Stats { get; }
    public ProtocolStats GetStatsSnapshot();
    public void ResetStats();
}

public interface ISerializer
{
    byte[] Serialize<T>(T obj);
    T Deserialize<T>(byte[] data);
    void Serialize<T>(IBufferWriter<byte> writer, T obj);
    T Deserialize<T>(ReadOnlySpan<byte> data);
}

public sealed class HyperionProtocolOptions
{
    public const int DefaultChunkSize = 1024 * 1024;
    public const int DefaultMaxHeaderLength = 64 * 1024;

    public int ChunkSize { get; init; } = DefaultChunkSize;
    public int MaxHeaderLength { get; init; } = DefaultMaxHeaderLength;
}

Exceptions that escape the receive/send paths are wrapped in HyperionProtocolException — bad magic, bad chunk order, header out of range, mismatched packet id, premature EOF.

Performance

Numbers from a typical dev box over loopback (Ryzen-class CPU, single TCP pair):

Test	Result
One-way 100 MiB — chunked HyperionProtocol	~290–340 MiB/sec
One-way 100 MiB — Pipelines path	~250–280 MiB/sec
One-way 100 MiB — ReceiveStreamingAsync	~430–500 MiB/sec (no buffering of the full payload)
SmartHyperionProtocol lightweight round-trip	~13 000–14 000 ops/sec, ~0.07 ms/op
100 concurrent clients, single round-trip each	~40 ms total

These come straight from the [Category("Performance")] NUnit tests in this repo. Run them yourself:

dotnet test src/TechTeaStudio.Protocols.Hyperion/TechTeaStudio.Protocols.Hyperion.sln -c Release \
    --filter "TestCategory=Performance|TestCategory=Stress" \
    --logger "console;verbosity=normal"

Each performance test asserts a generous lower throughput floor (30 MiB/sec) to catch regressions without flaking on slow CI.

For accurate, statistically-meaningful measurements there's a separate BenchmarkDotNet project:

dotnet run -c Release \
  --project src/TechTeaStudio.Protocols.Hyperion/TechTeaStudio.Protocols.Hyperion.Benchmarks \
  --framework net9.0 -- --filter "*"

It includes OneWayThroughputBenchmarks (NetworkStream vs Pipelines vs streaming receive across 64 KiB–64 MiB payloads with [MemoryDiagnoser]), SmartProtocolBenchmarks (round-trip latency across the lightweight / direct / chunked thresholds), and ConcurrentClientsBenchmarks (aggregate throughput at 10 / 50 / 100 clients).

Project layout

HyperionProtocol/
├── src/TechTeaStudio.Protocols.Hyperion/
│   ├── TechTeaStudio.Protocols.Hyperion.sln
│   ├── TechTeaStudio.Protocols.Hyperion/             <- NuGet package source
│   │   ├── Protocols/HyperionProtocol.cs             <- chunked protocol (base)
│   │   ├── Protocols/SmartHyperionProtocol.cs        <- adaptive framing
│   │   ├── Protocols/ChunkData.cs
│   │   ├── ISerializer.cs / DefaultSerializer.cs
│   │   ├── PacketHeader.cs / ProtocolStats.cs
│   │   ├── HyperionProtocolOptions.cs
│   │   └── HyperionProtocolException.cs
│   ├── TechTeaStudio.Protocols.Hyperion.Tests/       <- NUnit (correctness + perf + stress)
│   ├── TechTeaStudio.Protocols.Hyperion.Benchmarks/  <- BenchmarkDotNet console app
│   └── ConsoleTestApp/                                <- smoke test
├── .github/workflows/dotnet.yml                       <- CI publish (shared TTS workflow)
├── CHANGELOG.md
├── LICENSE
└── README.md

Build & test

dotnet build src/TechTeaStudio.Protocols.Hyperion/TechTeaStudio.Protocols.Hyperion.sln
dotnet test  src/TechTeaStudio.Protocols.Hyperion/TechTeaStudio.Protocols.Hyperion.sln

The library multi-targets net6.0;net8.0;net9.0;net10.0. net7.0 is intentionally skipped (EOL). The test and benchmark projects target net8.0;net9.0;net10.0 only — the NUnit3 test platform is unstable on net6.0.

Versioning & release

Version lives in TechTeaStudio.Protocols.Hyperion.csproj as a 3-part <Version>X.Y.Z</Version>. Bump rules:

• Bug fix → Z + 1
• New feature, source-compatible → Y + 1, reset Z = 0
• Breaking change in public API or wire format → X + 1 (after 1.0), reset Y = Z = 0

Commit format is vX.Y.Z <short description>. Push to main triggers the shared TechTeaStudio NuGet publish workflow, which packs and pushes to nuget.org with --skip-duplicate. Never push to nuget.org manually.

See CHANGELOG.md for the full release history.

License

Licensed under the MIT License. Copyright © Tech Tea Studio.

Built as part of the Hyperion Ecosystem by TechTeaStudio.
